Range : |
a) 20mV to 600V in different
ranges AC or DC.
b) 2 µA to 2000A in different ranges AC or
DC. |
|
Option : |
1] For C.T., Shunt, 4 to
20mA, 0 – 10V.DC etc. I / P , instruments
with desired calibration ratio & engineering
units can be supplied. |
|
2] Multifunction Panel
Meters. |
|
3]
Multi range Panel Meter. |
|
4] True RMS Meters, Peak
reading meter etc. |
|
Power : |
230V.AC, 110V.AC ± 15%,
50/60Hz, 5V.DC or 12V.DC |
|
Dimension : |
1] 96 X 96 X 60mm 2] 72 X
72 X 60mm
3] 48 X 96 X 110mm 4] 48 X 96 X 150mm ( For
4½ Digit )
5] 48 X 48 X 110mm 6]
96 X 96 X 110 (
For 4½ Digit
) |
|
Cutout : |
1] 91 X91mm 2] 67 X 67mm
3] 45 X 91mm
4] 45
X 91mm
5] 45 X
45mm |
